Description

High quality and reliability with functional design and easy installation
Switched both Live and Neutral
Type A for both AC and DC application
Compact size just 90mm x 18mm
Tested and Certified in accordance with IEC/BSEN61009-1
Breaking capacity: 6kA
Rated current: 32A
Number of poles: 1
RCD Type: A – Ensures tripping for residual AC currents and pulsating DC currents. Suitable for electric vehicle charging points
Curve Type: B – trips between 3-5 times full load current. Mainly used in residential applications where loads are resistive, such as lighting fixtures and domestic appliances.

Depth (mm) 18

mA 30

Width (mm) 79

Amp Rating 32

Breaking Curve B

Poles 1

Ref E-DLYC2132

Standards BSEN61009-1

RCD Type A

Short Circuit Breaking Capacity (kA)6

EAN: 5060690136361
