Description

Hager ADA316G 1 Module Single Pole Type B Reduced Height (92mm) 16A 6kA 30mA RCBO is designed for use in 18th Edition, Hager domestic consumer units providing protection for final circuits. This new ADA316G RCBO offers all the same functionality of the existing ADN RCBO range but in the more convenient compact size of a traditional MCB.

The RCBO combines the overcurrent functions of an MCB with the earth fault functions of an RCD in a single unit.

Hager ADA316G is a compact single module, single pole and solid neutral device to BS EN 61009-1 and BS IEC 1009-2-2 which has a positive indication for On or Off.

• Protects against earth leakage and against overloads and short circuits
• Reduced height provides increased wiring space during installation
• Removal of functional earth allows a faster neater installation
• Removal of functional earth makes testing easier and quicker
• Bottom din rail clip allows removal with no requirement to remove busbar
• Sensitivity : 30mA
• Breaking capacity : 6kA
• Single Module
• Complies with BS EN61009, IEC1009
• Positive Indication for On or Off

EAN: 3250611012979
