Description
CC332C
3 Pole 32Amps C Curve 10kA
Rated Current In (A): 6, 10, 16, 20, 25, 32, 40, 50, 63
Poles: 1P, 3P
Rated Voltage Ue(AC): 230/400V
Rated Frequency: 50/60Hz
Insulation Voltage Ui: 500V
Rated Breaking Capacity(A): 6/10kA
Rated Impulse Withstand Voltage(1.2/50) Uimp(V): 4000
Dielectric Test Voltage at ind. Frq for 1 min(kV): 2
Thermo-magnetic release characteristic: B, C, D
Electrical Life: 8000
Mechanical Life: 20000
Contact Position Degree: IP20
Reference temperature for setting of thermal element (°C): 30
Ambient temperature(with daily average =35°C : -5~+40)
Storage temperature (°C): -25~+70
EAN: 5060316235591
